It makes it possible to design high performance roofing in industrial contexts and it is also widely used in residential construction. In corrosive and marine environments, it guarantees higher durability compared to traditional metal sheets and panels.
Coverib 1000 can be integrated with any structural support, thereby satisfying various design and housing needs. This product is tough, lightweight and suitable for pedestrian access. It allows you to create sustainable roofing that is guaranteed over time and requires minimal maintenance, even in areas prone to high levels of corrosion and in harsh climates. It is Broof T3 certified and is the ideal support for photovoltaic systems.
Download dwg file
GR – Grey RAL 7023, W – Off White RAL 9002, N – Natural Alluminium, T – Terracotta RAL 8004, Q – Patina Green
FOLDED
CURVED
Multilayer protected sheet with trapezoidal profile, CE marked according to UNI EN 14782. Appendix A: complies with UNI EN 508-1 Appendix B: consisting of a structural galvanized steel sheet (EN 10346) with a thickness of 0,60 mm (ie mm 0,50) protected in the upper face by an anticorrosive and soundproofing thermoplastic coating (about 1.5 mm thick) and by a natural aluminum foil (or pre-painted aluminum), and in the lower face by a primer and a natural aluminum foil (or prepainted aluminum).
The external layers wrap the side edges of the sheets along the entire length to guarantee their full protection. To ensure the characteristics stability performances over time, the protection with anticorrosive and soundproofing function, has a thickness of about 1.5 mm and it is positioned on the extrados of the sheet.
The cover element ensures the following performance requirements:
Concentrated loads resistance |
Steel thickness 0,5: 1,2 kN span 1,50 m Steel thickness 0,6: 1,2 kN span 1,70 m (EN 14782 Appendix B) |
Reaction to fire: |
Class B-s1, d0 (UNI EN 13501-1; EN 13823; EN ISO 11925-2) |
Performances to external fire: |
Classe BRoof T3 (UNI EN 13501-5; UNI CEN/TS 1187) |
Durability – Salt spray resistance: |
4000 hours (UNI EN 14782 – Appendix A; ISO 9227) |
Durability – Humidity resistance: |
3000 hours (UNI EN 14782 – Appendix A; EN ISO 6270-1) |
Durability – SO2 resistance: |
45 cycles (UNI EN 14782 – Appendix A; EN ISO 6988) |
Sound insulation: |
28 dB (UNI EN ISO 10140-2:2010) |
Sound deadening of noise generated by driving rain: |
ISTEDIL cert. N°1302/202-G 1302/202-C 8,41 times higher than a 0,7 mm thick aluminium sheet 4,17 times higher than a sandwich panel with 40 mm insulation 52,3 dB UNI EN ISO 140-18 |
Solar Reflectance Index (SRI): |
Natural aluminium surfacing (N)107%; Grey – Off White RAL 9002 (W) 73,0%; Terracotta RAL 8004 (T) 41,1%; Grey RAL 7023 (GR) 42,6%; (ASTM E1980-11). |
Trasmittanza Termica Estiva: |
1,07 W/m2K (ISO 6946) with natural aluminium lower surfacing |
